Modern XC races look like a fast day on the local singletrack, requiring a light and capable bike that can maintain speed and control on every part of the trail, up or down. The Team Marin blends the confidence and fun of a trail bike with a lightweight frame and parts that help you keep the speed up and the fun meter maxed.

Series 4 Aluminum Frame
The Team Marin features Series 4 aluminum frames, with advanced tube forming for minimal weight, 3D forged dropouts, flat-mount disc tabs, full internal cable routing, and a boost 148mm thru axle.

Internal Dropper Post Routing
The Team Marin frame includes internal routing in the front triangle for a clean, fast appearance, and allowing for Team Marin 1 owners to upgrade to an internal dropper post if they desire.

Bridgeless Fastback Seatstays
Slim fastback seatstays, without the bridge, give great tire clearance, as well as adding vertical compliance for long-ride comfort without sacrificing power transfer.

29" Wheels And 2.35" Tires For Maximum Speed
29" wheels and 2.35" XC tires ensure maximum grip and float over obstacles to maintain speed so you can pick up those personal records and keep ahead of the pack.

- Superlight aluminum frame
- RockShox Judy Silver TK 120mm fork
- Shimano Deore 1x12 drivetrain
- Shimano BR-MT201 hydraulic disc brakes


Frame Series 4 6061 Aluminum, 29" Wheels, Superlight Aluminum Frame, Post-Mount Rear Brake, Internal Shifter and Dropper Post Routing
Fork RockShox Judy Silver TK, 120mm Travel, Alloy Tapered Steerer, Solo Air Spring, Maxle Stealth, 51mm Offset
Headset FSA No 42ACB, 1 1/8" x 1 1/2"
Axles Front: 110 x 15mm thru-axle
Rear: 148 x 12mm thru-axle
Rims/Wheels Marin Aluminum Double Wall, 29mm Inner, Sleeve Joint, Disc Specific, Tubeless Compatible
Hubs Front: Forged Aluminum, Centerlock Disc, 32H
Rear: Shimano, MicroSpline, Centerlock Disc, 32H
Spokes 14g Black Stainless Steel
Tires Vee Tire, Rail Rocco XC, 29x2.3", Dual Control Compound, Folding Bead, Tubeless Ready
Crankset Marin Forged Alloy 1x12, Hollow Spindle
Chainrings Steel Narrow Wide 32T Direct-Mount
Bottom Bracket External Sealed Cartridge Bearings
Chain KMC X12
Rear Derailleur Shimano Deore 12-Speed
Cassette/Rear Cogs Shimano Deore 12-Speed, 10-51T
Shifters Shimano Deore 12-Speed
Handlebars Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Tape/Grips Marin Single Clamp Locking
Stem Marin 3D Forged Alloy, 35mm
Brake Levers Shimano BL-MT201 Hydraulic
Brakes Front: Shimano BR-MT201 Hydraulic Disc, 180mm Centerlock Rotor
Rear: Shimano BR-MT201/UR300 Post-Mount Hydraulic Disc, 180mm Centerlock Rotor
Pedals Nylon Platform
Saddle Marin Speed Concept
Seat Post Marin Alloy, 30.9mm

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Gloss Chrome/Black / Small 843346107749 732415001
Gloss Chrome/Black / X-Large 843346107770 732415004 210000007990
